1000 BPH Complete Poultry Processing Solution

1000 BPH Complete Poultry Slaughterhouse Solution

1. Project Overview

The 1000 BPH poultry slaughterhouse solution is a standard mid-capacity processing concept developed by Qingdao Raniche Machinery Technology Co., Ltd., designed to showcase our ability to plan complete, practical, and internationally applicable poultry slaughterhouses.

This solution is one of the most widely requested capacities in global markets, offering a balance between production efficiency, investment cost, and operational flexibility.

The design serves as a reference layout, allowing customization according to different countries, poultry types, hygiene standards, and end-product requirements.

2. Design Positioning & Application Scenario

The 1000 BPH solution is positioned as a core commercial slaughterhouse model, suitable for customers who:

• Supply regional or city-level markets

• Export fresh or frozen whole chicken

• Require mechanized processing with moderate labor input

• Plan future expansion to higher capacities

This layout follows internationally accepted poultry processing logic and can be adapted for Halal slaughter, manual or semi-automatic operation.

3. Processing Flow Description

The slaughtering process follows a clear and continuous workflow:

1. Live bird receiving and crate handling

2. Stunning or manual slaughter

3. Bleeding section

4. Scalding

5. Defeathering

6. Head removal

7. Evisceration and inspection

8. Feet cutting and unloading

9. Carcass washing

10. Pre-chilling

11. Packing or transfer to further processing

The process is designed for stable operation and easy management.

4. Functional Layout Planning

Live Bird & Slaughter Area

Includes crate conveyors, overhead killing line, stunning/slaughter stations, bleeding troughs, scalding and plucking machines.

 Evisceration & Processing Area

A semi-clean zone equipped with evisceration troughs, inspection tables, feet processing and organ handling equipment.

 Pre-Chilling Area

Designed to rapidly reduce carcass temperature before packing or further processing.

 Packing & Dispatch Area

Includes working tables, packing machines, and temporary storage space.

 Auxiliary Areas

Staff hygiene rooms, equipment cleaning areas, and basic technical rooms.

The layout ensures a logical flow from dirty to clean zones.

5. Main Equipment Configuration

Slaughtering Section

• Overhead conveyor system

• Crate conveying system

• Stunning device / Halal slaughter position

• Bleeding trough

• Scalder

• Vertical plucker

• Head cutter

Evisceration & Feet Processing

• Evisceration conveyor and trough

• Automatic feet cutter

• Feet unloader

• Shackle washer

Chilling & Packing

• Pre-chiller

• Carcass transfer trough

• Working tables

• Packing machine

Organ Processing

• Gizzard oil & grease removing machine

• Gizzard peeler machine

Final equipment configuration can be adjusted according to customer needs.

6. Optional Expansion & Customization

To adapt this 1000 BPH solution to different markets, the following systems can be optionally added:

• Flake ice machine

• Steam generator or boiler

• Cold storage rooms

• Cutting and deboning section

• Wastewater treatment system

This flexibility makes the solution suitable for a wide range of projects.

7. Typical Markets & End Products

This solution is commonly applied in:

• Africa

• Southeast Asia

• Middle East

• Latin America

• Eastern Europe

End products may include:

• Whole chicken

• Simple cut-up portions

8. Why the 1000 BPH Solution Is a Key Reference for Raniche

This project highlights Raniche’s capability to:

• Design complete poultry slaughterhouses across different      capacities

• Provide scalable and upgradeable layouts

• Adapt solutions to various international standards

• Support customers from basic processing to industrial expansion

It acts as a bridge solution between small starter lines and large industrial plants.

For customized layouts, equipment lists, and quotations of a 1000 BPH poultry slaughterhouse, please contact Qingdao Raniche Machinery Technology Co., Ltd.
Our engineering team will design a solution based on your specific market and production needs.
